Polyethylene Splice Sleeve Protector Fiber Optic 60mm Side Shrink
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Side Shrink Type PE Outer Tube 60mm Length 2.5mm Diameter Fiber Optic Heat Shrink Sleeves | Use | Single Fiber Splice Protection |
|---|---|---|---|
| Brand | Focus Infra Or OEM | Material | PE Outer Tube, Stainless Steel Rod, Eva Inner |
| Application | Fiber Splicing Protect | Length | 60mm |
| Diamter | 2.5mm | Color | Clear |
| Operating Temperation | -45°C To +120°C | Place Of Origin | China |
| High Light | PE sleeve protector fiber optic 60mm,PE fiber optic 60mm,PE fiber optic 60mm Side Shrink |
||
Product Description
Side Shrink Type PE Outer Tube 60mm Length 2.5mm Diameter Fiber Optic Heat Shrink Sleeves
Description:
Side Shrink Type PE Outer Tube 60mm Length 2.5mm Diameter Fiber Optic Heat Shrink Sleeves is consisted of cross linked polyolefin, hot melt tubes and stainless reinforcing steel rod which keep optic transmission properties of optical fiber and enhance the protection to optical fiber splices. Side Shrink Type PE Outer Tube 60mm Length 2.5mm Diameter Fiber Optic Heat Shrink Sleeves is widely used in communication optical fiber equipment such as optical fiber splice box, optical fiber terminal box, optical fiber distribution box, optical fiber transfer box, etc. When using Side Shrink Type PE Outer Tube 60mm Length 2.5mm Diameter Fiber Optic Heat Shrink Sleeves, it can not only protect the splice point but also increase the optical fiber machinery the strength reduces the damage of the optical fiber during the installation process without affecting the light guide characteristics of the optical fiber.
Features:
1. PHigh transparent fiber fusion splicing heat shrinkable tube
2. 60mm non-stick inner wall, fast welding
3. No air bubbles, no fiber breakage
4. Strong practicality
5. extend the service life of the fiber
6. Selected 304 high-quality stainless steel, not easy to rust, corrosion-resistant, and anti-aging
Technical Parameters:
|
Specification |
Test method |
Typical data |
|
Tensile strength(MPa) |
ASTM D 2671 |
18 |
|
Elongation at Break (%) |
ASTM D 2671 |
700 |
|
Density(g/cm2) |
ISO R1183D |
0.94 |
|
Dielectric strength (KV/mm) |
IEC 243 |
20 |
|
Permittivity |
IEC 243 |
2.5 |
|
Length rate of change (%) |
ASTM D 2671 |
+5 |
