OEM Outdoor Horizontal Fiber Optic Splice Closure 3 Inlets 3 Outlets
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Horizontal Type 3 Inlets 3 Outlets 96 Core Fiber Optical Cable Joint Enclousre | Model Number | FS-J-009 |
|---|---|---|---|
| Brand Name | Focus Infra Or OEM | Protection Level | IP 68 |
| Cable Port | 3 Inlets 3 Outlets | Scope Of Application | 12 Core To 72 Core |
| Product Size | 445*220*105mm | Gross Weight | 2.9 Kg |
| Main Material | PC Alloy | Ambient Temperature | - 40 °C ~ + 60 °C |
| High Light | OEM horizontal fiber optic splice closure,outdoor fiber enclosure 3 inlets,outdoor fiber enclosure 3 outlets |
||
Product Description
Horizontal Type 3 Inlets 3 Outlets 96 Core Fiber Optical Cable Joint Enclousre
Description:
Horizontal Type 3 Inlets 3 Outlets 96 Core Fiber Optical Cable Joint Enclousre, also known as Horizontal Type 3 Inlets 3 Outlets 96 Core Fiber Optical Cable Joint Enclousre Box, is the place where the end of optical cable is connected. Then it is connected to optical switch through optical fiber jumper to prevent material aging caused by heat, cold, light, oxygen and microorganisms in nature. Horizontal Type 3 Inlets 3 Outlets 96 Core Fiber Optical Cable Joint Enclousre are widely apply for the connecting of optical cable.It Suitable for straight-through, diverging and connection of FTTH. FTTB all kinds of optical communication passive network.
Features:
Ageing resistance & ultraviolet radiation resistance
Advanced internal structure design
Easy and fast to fix fiber cable
The closure is spacious enough for winding and storing fibers
Grouping function: 3 inlet 3 outlet can meet most requirements
Splice tray: using cascading structure, no need to take other splice tray when do operation
IP68 Water-proof design for outdoor uses;
The application of temperature: -40℃~60℃
Specification:
| Product name | Horizontal Type Vertical Fiber Optic Splice Box |
| Protection level | IP68 |
| Scope of application | 12 core to 96 core |
| Gross weight | 2.9 kg |
| Main material | PC alloy |
| Scope of use | Outdoor Aerial Dome,Buried,pole mount type outdoor |
| Ambient temperature | - 40 °C ~ + 60 °C |
| Service life | ≥20 years |
| Application scope | FTTH FTTB FTTX Network |
| Atmospheric pressure | 70kPa~106kPa |
| Insulation resistance | >2*10MΩ/500V(pc) |
| Tensile strength | >1200N |
