FTTH ABS 16 Core Fiber Optic Distribution Box 1.3kg OEM Focus Infra

Place of Origin China
Brand Name Focus Infra or OEM
Model Number 16 cores Fiber Optic Distribution Box
Minimum Order Quantity 50PCS

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name FTTH 16 Core Cassette Fiber Optic PLC Splitter 1 X 16 Fiber Optic Splitter Distribution Box Brand Focus Infra Or OEM
Model Number FOCC-F-004 Type Racks & Enclosure
Color White, Black Texture Of Material ABS Or PP
Product Size 320*260*100mm Net Weight 1.3 Kg
Cores 16 Cores Application Temperature -40℃~ +80℃
Cable Port 2 Entry Port + 16 Drop Cable Port Protection Level IP65
High Light

ABS Fiber Optic Distribution Box

,

16 core distribution box 1.3kg

,

16 core distribution box OEM

Leave a Message
Product Description

FTTH 16 core Cassette Fiber Optic PLC Splitter 1 X 16 Fiber Optic Splitter Distribution Box

The equipment is used as a termination point for the feeder cable to connect with drop cable in FTTx communication network system. The fiber splicing, splitting, distribution can be done in this box, and meanwhile it provides solid protection and management for the FTTX network building.



Description:



  Fiber Optic Distribution Box is used for outdoor, corridor or indoor connection trunk optical cable and cable distribution interface equipment. The fiber distributor box must be able to work reliably in the specified environment, and its box can withstand a vertical pressure of not more than 500N.

  Optical fiber distribution box is a client wiring device in FTTH optical network. It is mainly used for terminal fusion, optical splitting, wiring output and other functions of optical transmission terminals. It can effectively connect, protect and manage optical cables, and is a necessary device in the transmission process of optical network. 12 core 16 core 24 48 core optical fiber core 32 core 36 core points fiber boxes, cable fiber box is for FTTH construction use the different scenarios such as primary spectral or secondary spectral demand and development and design of a new product, the product is used for wiring cable by optical divider and butterfly door cable connection, so as to meet the needs of users rate high bandwidth business opened, It is an important optical access point device in ODN. It is suitable for a variety of scenarios: indoor, outdoor, hanging wall, hanging rod, new and old buildings. Molded box body, installation backplane design, beautiful and compact shape, convenient installation, convenient for large-scale construction.
