L60mm Fiber Optic Splice Sleeves Dia 2.7mm Heat Shrink Splice Protector

Place of Origin China
Brand Name Focus Infra or OEM
Model Number 1.2*60MM
Minimum Order Quantity 50000pcs
Price Negotiable
Packaging Details 100pcs/bag
Delivery Time 15 days
Payment Terms T/T
Supply Ability 3000000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Product Name 60mm 2.7mm Diameter Fiber Optic Splice Sleeves Use Single Fiber Splice Protection
Brand Focus Infra Or OEM Material Heat Shrink Tube, Stainless Steel Rod, Fusion Tube
Application FTTH Length 60mm
Diamter Of Steel Rod 1.2mm Diamter Of After Shrink 2.7mm
Outer Tube Materials PE Inner Tube Materials EVA
Color Clear Operating Temperation -45°C To +120°C
Place Of Origin China Pack 100pcs/bag Or Negotiable
High Light

L60mm Fiber Optic Splice Sleeves Dia 2.7mm


L60mm heat shrink splice protector 2.7mm


Dia 2.7mm heat shrink splice protector

Leave a Message
Product Description

L60mm Standard Diameter 2.7mm Transparent Fiber Optic Splice Sleeves





 A Fiber Optic Splice Sleeve is consisted of cross linked polyolefin, hot melt tubes and stainless reinforcing steel rod which keep optic transmission properties of optical fiber and enhance the protection to optical fiber splices. It is friendly operated to the optic fiber during installation without damaged and micro bending.



How to use a Fiber Optic Splice Sleeve?


 The Fiber Optic Splice Sleeve was developed to protect and strengthen fusion splices on fiber optic cables. We must be installed on the optical fiber before fiber fusion (otherwise, you will have to break the optical fiber and start again).

 First, slide the Fiber Optic Splice Sleeve onto the optical fiber.

 Then weld the two optical fibers. After the welding is completed, slide the sleeve onto the optical fiber fusion point and cover the connect point and the exposed optical fiber.

 Third, put the protective sleeve into the protective sleeve oven built in the welding machine. There, the Fiber Optic Splice Sleeve is heated to melt and contract around the joint.

 Because the Fiber Optic Splice Sleeve has steel rods, a mechanical protection is formed to prevent the fiber from bending. The contraction of the tube around the optical fiber also forms an environmental protection to keep the element away from the connector.



Product parameter:


Product name: fiber heat shrinkable tube

Steel needle material: 304 stainless steel rod

Outer skin material: environmentally friendly PE

Product unit: 100 pcs per bag

Length dimension: 60 mm 45 mm 40 mm

Product color: transparent



Technical Parameters:


Test method

Typical data

Tensile strength(MPa)

ASTM D 2671


Elongation at Break (%)

ASTM D 2671



ISO R1183D


Dielectric strength (KV/mm)

IEC 243



IEC 243


Length rate of change (%)

ASTM D 2671
